BorgWarner AirWerks S300SX Turbo 1.00 A/R - 59/76
BW part number 177278
Genuine BorgWarner AirWerks turbocharger
Note: Currently, some compressor housings come without a logo! This is not a difference in quality! All components come directly from BW USA from the factory.
AirWerks S300 turbochargers from BorgWarner Turbo Systems are dedicated aftermarket turbos for the performance sector. Proven line-produced parts (mostly from Schwitzer Turbo) are being combined to deliver high end tuning and motorsports performance while maintaining an ideal price/performance ratio.
performance rating: 320 - 660 HP
compressor housing: intake 101mm / pressure side 76mm (parallel to intake)
compressor wheel: inducer 58,50mm / exducer 81,28mm
turbine housing: 1.00 AR / header flange T4 Twin Scroll / turbine outlet BorgWarner V-Band
turbine wheel: inducer 76,20mm / exducer 67,56mm / external wastegate
- dual hydrodynamic journal bearing
- extended tip technology
- Twin Scroll turbine housing (singlescroll housings available)
- adjustable orientation of compressor housing and turbine housing
- compressor housing with anti-surge ports (High-Flow)
Different A/R ratio?
If you order an AirWerks turbocharger and wish to have a different AR turbine housing, you have to order the corresponding turbine housing separately.- Flange type: T4 divided / TwinScroll
- Turbocharger: S300,S300SX
- a/r Value: 1.00ar
