Screw-in adapter M16 x 1.5 to Dash 8 / -08 AN

Item number: 3709990362

£ 4.78

including 20% VAT. , plus shipping


 Stock:
more than 20
 Shipping time
Available now!

Screw-in adapter M16x1.5 to Dash 8 / -08 AN

Hydraulic Adapter Metric to Dash External thread

Aluminium CNC milled, black anodized

With our screw-in adapters you are able to to use our hydraulic lines for your own construction even where there are only metric connection possibilities on the vehicle side. This is particularly the case for European vehicles. All adapters are CNC machined from aluminum and black anodized afterwards. Due to the anodization the adapters can be used with all liquids (oil, fuel, E85, cooling water, etc.) When designing the screw-in units we took care to achieve the largest possible bore with the greatest possible wall thickness. This ensures that each adapter is stable enough and offers the highest possible flow rate.

Material: Aluminium
Colour: Black anodized
Thread A: M16x1,5
Thread B: Dash 8 / -08 AN
Total length: 38mm
Length Thread A: 12mm
Length Thread B: 17mm
Bore: 10mm
Width across flats: 22mm


EAN: 4063087134576
Model: Screw-in fitting
Thread: M16 -8AN / Dash 8
