Radiator Mishimoto for Subaru WRX and STI / 08+ / Manual / 3 Row

This Mishimoto Subaru aluminum radiator is the ideal upgrade for your standard radiator. It has been designed and developed to maximize cooling efficiency, improve engine functions, and most importantly, protect your vehicle from overheating. Whether you use your Subaru for daily driving or only on the racetrack, installing an upgraded radiator is essential if you want to reduce the risk of engine failure.
The Mishimoto radiator features a lightweight three-row core, 100% brazed aluminum, and polished end tanks. The performance of your engine will be increased. This Mishimoto radiator is a direct OEM replacement, making installation effortless as no cutting or modifications are needed. Included in the package is a 1.3 bar high-pressure radiator cap. This radiator cap increases the boiling point of the coolant, providing a higher margin for acceptable temperatures and creating a safer and more efficient cooling system. Additionally, a magnetic Mishimoto drain plug is included, which collects metallic fragments circulating in the cooling system, protecting your engine. Whether you're looking for a reliable replacement radiator for your current standard or one efficient enough to withstand track demands, the Mishimoto Subaru radiator is the ideal choice.

Note: This product is for vehicles with a manual transmission. For automatic vehicles, please purchase the Mishimoto radiator: MMTC-U. For 2015 STI models, there will be some clearance between the overflow tank and the pump.Radiator Cap:
The included Mishimoto radiator cap should be used to replace the manufacturer cap on the expansion tank. The manufacturer radiator cap connected to the radiator should be used for the Mishimoto performance radiator. The Mishimoto radiator cap is a two-way valve, whereas the manufacturer radiator cap is a one-way valve. Due to this design difference, the Mishimoto radiator cap cannot be used for this radiator. Using the Mishimoto radiator cap on the radiator can lead to overheating.

Attention:
It is the responsibility of the installer to ensure all thermostat connections, NPT fittings, line fittings, and other connections are fully tightened before using the vehicle. Mishimoto recommends checking all connections at regular intervals, especially after the first few miles following installation. Please contact us for further technical questions.
Use small fittings for:08

Technical Data:
Overall Height: 711mm
Overall Length: 553mm
Overall Width: 63mm
Core Height: 688mm
Core Length: 340mm
Core Depth: 50mm
Core Dimensions: 340mm x 688mm
Rows: 3
Inlet: 1.54
Outlet: 1.54
Wall Thickness: 2mm
Filler Neck: 1.22
Filler Neck Width: 0.12
Drain Plug Thread Size: (M16) .06
Drain Plug Length: 0.047
DPI: 13091/13093
Engine Code:
- EJ255
- EJ257
Chassis Code:
- GE
- GH

Compatible with:
- 2008-2014 Subaru Impreza WRX 2.5 Liter TY758
- 2010-2014 Subaru Impreza WRX Limited 2.5 Liter TY758
- 2009-2014 Subaru Impreza WRX Premium 2.5 Liter TY758
- 2008-2014 Subaru Impreza WRX STI 2.5 Liter TY856
- 2011-2014 Subaru Impreza WRX STI Limited 2.5 Liter TY856
- 2010 Subaru Impreza WRX STI Special Edition 2.5 Liter TY856
- 2005-2006 Subaru Legacy GT 2.5 Liter TY757
- 2005 Subaru Legacy GT Limited 2.5 Liter TY757
- 2007 Subaru Legacy GT Limited 2.5 Liter TY757
- 2008-2009 Subaru Legacy GT Limited 2.5 Liter TY758
- 2008-2009 Subaru Legacy GT Limited 2.5 Liter TY758
- 08-15 STI
- 08-14 WRX
- 11 STI Limited
- 11 Forester XT Touring
- 10+ WRX Limited
- 10+ WRX Premium
- 10+ Forester XT Premium
- 10 STI Special Edition
- 09-10 Impreza 2.5 GT
- 09-10 Forester XT Limited
- 09 Forester XT
- 08 Outback 2.5 XT
- 08 Legacy GT
- 07-09 Outback

Package Includes:
- Mishimoto Radiator
- Mishimoto Radiator Cap
- Union Nipples - 2
- Magnetic Drain Plug
