SWD32 GEN2 - for dished sports steering wheels

Enables real-time display of engine data on/at the steering wheel

The SWD32 display fits any dished sports steering wheel with a bolt circle of 6x70

With the CANchecked SWD32 GEN2 data display, you always have all the data in view

The SWD32 GEN2 fits any dished sports steering wheel with a bolt circle of 6x70 and a horn hole and is an intelligent display with features you won't want to miss. The lightweight plastic housing impresses with its symmetrical appearance.

Key Features

• Can Bus:&nbspRead deep vehicle data like manufacturer diagnostic tools
• Gear Indicator:&nbspDirectly via&nbspCan Bus or calculated from speed and RPM
• Touchscreen: Navigate through intuitive swipe gestures through the pages
• Customization:&nbspCreate your own pages, add your own images or a custom start animation
• Additional Inputs:&nbspConnect up to 4 analog inputs and an ethanol sensor directly to the display
• Can Switching: Use your display as a keypad and send custom Can messages on the bus
• Customizable Alarms: Individual&nbspwarnings can be easily configured and activated. For example, get a large warning message when the exhaust temperature exceeds 900 degrees
• Logging:&nbspLog and save your data for later analysis on the internal SD card
• Performance Meter:&nbspMeasure your 0-100, 100-200, and 0-200 times with the integrated performance meter without additional hardware
• DTC*:&nbspRead and clear errors from engine control unit, transmission, ABS, and all-wheel drive
• Dimming*:&nbspYour display dims automatically along with the instrument panel

Different Views

Configure your own page or choose from various pre-made views:

• The display comes with predefined example pages
• Creating your own pages is possible and encouraged
• Up to ten pages possible
• 20 different widget types (e.g., sensor value, analog pointer, YT diagram, RPM bar, round display, vertical/horizontal bar)
• Widgets are scalable in size and can be positioned using drag and drop
• Widget colors are fully adjustable
• Up to 64 widgets per page

Display Setup Software - DSS

With the CANchecked DSS, you can fully customize your display to your preferences. With the integrated log viewer, you can&nbspdownload and view the log files. Additionally, a Can logger is integrated. The heart is the integrated&nbsp"TRI-Editor",&nbspwith which you can adjust the sensors (whether Can Bus or internal): Assign min/max values for warnings and change the names of your sensors.&nbsp

Supported Values

Many customers always ask: "Which values can I query from my control unit". The answer: "ALL"

We have reverse-engineered the data for most engines and can offer deep data. Our display supports Can Bus data query (UDS, TP2, manufacturer-specific protocols) (ISO 9141) and OBD2.

By default, your display comes with pre-made TRI-/TRX-files. In the files, all sensors are defined, which are queried. These vary from engine to engine. Here is an excerpt of what is possible:

Temperatures:

• Exhaust temperature, coolant temperature, oil temperature, intake temperature, outside temperature, fuel temperature, DSG temperature

Pressures:

• Boost pressure, ambient pressure, fuel pressure pre-supply pump, rail pressure actual/target

Lambda/Mixture

• Lambda value, injection time, short-term lambda adjustment, long-term lambda adjustment

Miscellaneous

• RPM, air mass, vehicle speed, throttle angle, total ignition angle, ignition angle reduction per cylinder, N75 actuation in %, terminal 30 voltage, torque, gear, diesel-specific values

If values are missing, they can be added later by us.

Of course, your new data display supports a wide range of freely programmable control units such as:

• DTA Fast
• Ecumaster
• Emerald
• Emtron
• Haltech
• Hondata
• KMS van Kronenburg
• LinkECU
• MaxxECU
• MBE
• Megasquirt
• Motec
• Motorsport Electronics
• Syvecs
• Trijekt
• VEMS

Scope of Delivery

Each delivery includes:

• SWD32 GEN2 data display with lightweight plastic housing
• Connector A (8-pin Molex)
• Connector B (10-pin Molex)
• Pre-configured connection cables in various colors (length: 20&nbspcm, purpose: power supply, Can Bus, analog inputs, 5V, sensor ground)
• Pins for self-crimping
• Two 1K resistors (as pull-up for connecting external NTC sensors)
• Quickstart Guide
• USB data cable
• SD card (pre-installed in the display)
• SD card adapter
• Display film (to prevent reflections)

Connection and Expansion

Any sensors can be connected via the four analog inputs – we support both linear 0-5V and NTC sensors.
Our in-house CANchecked sensors&nbspare standardly stored in the TRI-/TRX-files and only need to be connected:

• AIN1: Temperature sensor (NTC01)
• AIN2: Converter for exhaust temperature probe type K (TCC01)
• AIN3: Pressure sensor 0-10 Bar (FLP01)
• AIN4: Boost pressure sensor 0-5.5 Bar absolute (BST01)

You can use our pre-configured AIN cable harness for connection.

In addition to the analog sensors, you can also connect our external shift light with 8 LEDs. This can flash in different colors, and the RPM limits and colors can be configured directly on the display.

The ethanol sensor is connected directly to the display. You need a pull-up resistor (10K) between 5V and signal. Then you can view and log the ethanol content and temperature directly on the display.

Advanced Functions

With the&nbspMath-Channels&nbspyou can calculate sensors with each other. The&nbspUser-Tables&nbspgive you the opportunity to generate additional sensors using 2D or 3D maps.&nbsp

Optional Accessories

• CC10001 GPA32 - 52mm slot adapter for SWD32(S)
• CC24000 SLM08 - external shift light module
• CC22780 ANC04 - fourfold AIN cable harness 300cm
• CC22100 CBD08 - eightfold Can distribution hub
• CC22902 NTC01 - temperature sensor for liquids 1/8" NPT
• CC22903 TCC01 - type K converter 0-1250°C
• CC22901 FLP01 - pressure sensor 0-10 Bar (145psi) M10x1
• CC22900 BST01&nbsp-&nbsppressure sensor 6.5 Bar relative (95psi)

*not available with all protocols
