Top-Mount Intercooler Kit Mishimoto for Subaru WRX / 08-14 / Silver Intercooler / Black Silicone

279mm x 279mm x 89mm

Available Options:
silver intercooler, black intercooler
black, blue, or red hoses

Design: Bar-and-Plate
Tube Construction: polished aluminum
Overall Length: 470mm
Overall Height: 318mm
Overall Width: 127mm
Core Length: 279mm
Core Height: 279mm
Core Width: 89mm
Core Size: 279mm x 279mm x 89mm
Inlet: 48mm
Outlet: 70mm
Fin Specifications:
Internal: 6.5mm fin height, 2.8mm fin angle
External: 6.5mm fin height, 1.7mm fin angle
Tank Wall Thickness: 3.5mm
Weight: 9.5kg

Chassis No:
GR
GV
Engine Code:
EJ255

Intercooler/Throttle Body Coupler Specifications:
Inner Diameter: 70mm
Outer Diameter: 80mm
Wall Thickness: 101.6mm

Note:
This kit is designed for 250-350 whp with a maximum limit of approximately 400 whp or 2.06 bar of boost. A larger front-mount intercooler may be required for higher horsepower or boost.

Purchase Includes:
(1) Top-Mount Intercooler
(1) Intercooler to Throttle Body Hose
(1) Turbo to Intercooler O-ring Gasket

Fits:
08-14 Subaru WRX
05-09 Legacy GT
05-09 Outback XT
09-13 Forester XT

Are you looking for a way to reduce the high intake temperatures of your WRX, whether it's modified or not? The solution is the direct-fit Mishimoto WRX Top-Mount Intercooler, designed specifically for the Subaru WRX model years 2008-2014. The factory WRX intercooler is prone to heat soak and even failure of the plastic end tanks above 1.24 bar. Mishimoto engineers have spent months designing and testing this new WRX Top-Mount Intercooler to ensure optimal performance for both street and track.
This WRX Top-Mount Intercooler features durable, cast aluminum end tanks, TIG-welded for a highly efficient and dense bar-and-plate core. The Mishimoto WRX intercooler boasts a 95mm core and a total volume of 9570cm³. Thanks to this volume and a dense, staggered fin pitch, we are able to optimize heat transfer and support vehicles with up to 400 whp with this intercooler. Extensive testing has demonstrated a temperature drop of 6.67°C as well as +6 whp and +8 Nm of torque increase on our unmodified test vehicles. Installation is straightforward, requiring no modifications to any parts in the engine bay, and can be completed in under 30 minutes.
This top-mount intercooler comes with a new turbo to intercooler O-ring gasket and a Mishimoto silicone coupler for the throttle body. With these WRX parts, you won't need to gather any additional accessories for installation, and our products are designed for years of reliable service. This WRX Top-Mount Intercooler is available with a durable powder coat finish in silver or black.
