Performance intercooler kit KTM X-Bow

Wagner Tuning high performance intercoolers, downpipes, intakes and more

Experience the ultimate performance upgrade for your KTM X-Bow with the WAGNERTUNING high performance intercooler!
The 2.0 TFSI turbo engine of the KTM X-Bow has an indirect charge air cooling circuit, where the cooling process of the charge air is done by a water-cooled intercooler. With our specially designed high performance intercooler from WAGNERTUNING you replace the original intercooler and experience a revolutionary increase in performance.

Our high performance intercooler features an innovative performance mesh with dimensions of 222 mm x 297 mm x 95 mm. It was developed specifically for the high demands of the KTM engine and offers an incredible 80% more external mesh volume compared to the stock intercooler. The ratio between internal and external cooling surface ensures maximum heat transfer and optimal internal airflow. The cast aluminum end boxes were designed using state-of-the-art CAD technology and optimized by CFD simulations. The result is outstanding cooling properties with minimal back pressure, increasing air mass flow by an impressive 33%. This also makes our kit ideal for racing. You benefit from optimum cooling of the supercharged air and a significant increase in performance.

To ensure a lasting cooling effect, all WAGNERTUNING charge air coolers are provided with a heat-conducting anti-corrosion coating. The installation of the system is uncomplicated thanks to our detailed installation instructions and a direct replacement of the original intercooler is possible.

Advantages of this product:
- Direct replacement for the original intercooler.
- Significantly improved cooling performance
- 80 % more outer net volume
- 33 % more air mass flow and lower back pressure
- More power and torque for your engine
- Mechanical relief of the turbocharger
- All-aluminum intercooler, pressure stable up to 6 bar (tested)
- LLK connection towards throttle body enlarged from Ø62 mm to Ø70 mm

Experience the power of the WAGNERTUNING high performance intercooler and maximize the performance of your KTM X-Bow to a new level!

Performance intercooler fits the following models:
KTM X-Bow 177-210KW/240-286PS (2008-2017) K03 Turbo.
KTM X-Bow GT 220KW/299PS (2017+) K04 Turbo
KTM X-Bow R 220KW/299PS (2010+) K04 Turbo

Mains dimensions OEM intercooler:
180mm x 218mm x 90mm
V = 3,5 liter

Mains dimensions WT intercooler:
222 mm x 297 mm x 95 mm
V = 6.3 liters

Part number: 200001169
Kit comes with:
Please select the desired version.
