Manifold gasket T4 / TwinScroll S200SX-E / S200 / S200SX
High-quality turbo metal gasket for BorgWarner AirWerks turbochargers
Gasket between manifold and turbocharger for S200SX-E / S200 / S200SX
The gasket is made of stainless steel die-cut. The imprinted grooves put the sealing surface exactly where needed. Please keep in mind that each assembly and disassembly requires a new gasket.
Material: Stainless steel
Overall dimensions: 108 mm x 94 mm
Dimensions cut-out: 51 mm x 36 mm.
Hole spacing: 83 mm x 70 mm
For / Fits
Turbocharger T4 / BorgWarner AirWorks with TwinScroll turbine housing
AirWerks S200
AirWerks S200SX
AirWerks S200SX-E
If you are not sure if this flange fits to your turbocharger, you can make a sketch of your turbine inlet flange, we will compare it!
- Usage: Manifold to turbocharger
- Flange type: T4 divided / TwinScrollT4 Twinscroll
- Turbocharger: AirWerks S200Airwerks S200SXBorgWarner AirWerksS200S200SXS200SX-E
- Availability: available today
- Model: Gasket
