Intercooler - TR1235R - 1340 HP
High efficient Motorsport Bar-and-Plate Intercooler
With cast end tanks, solid intercooler with great cooling efficiency
Treadstone Performance Engineering Rated-R Intercoolers are mainly used on side mount twin turbo applications where we can sacrifice ambient external air flow because there isn't a radiator behind each core that requires airflow. By eliminating the radiators need for airflow, we are able to shrink the ambient fin height, and add this to internal flow. These Rated-R cores will also be found on full race intercooler set ups on large front mount intercoolers.
This R core, with our standard bar height, is rated for 1340 HP and 2010 CFMwhile the normal TR1235 is rated for 900 HP and 1469 CFM. (22" x 12.5" x 3.5"). Since this unit has 22 internal passage ways compared to 18, this core allows higher internal flow and less pressure drop. These cores are mainly used on side mount twin turbo applications where we can sacrifice ambient external airflow because there is not a radiator behind each core that needs air flow. Eliminating the radiators need for airflow, we can shrink the ambient fin height, and add this to internal flow. These Rated-R cores will also be found on full race intercooler set ups on large front mount intercoolers.
Core Size: 318mm x 559mmx 89mm
Overall length: 762 mm
Less than 0,1 bar pressure drop at max flow
76mm inlet/outlet
89mm core, 2010 CFM flow rate, 1340 HP efficient, 0,1 bar drop
