Downpipe Flange V2A 4-bolt 63mm / 70mm
Flange for fabrication of the downpipe
Premium stainless steel downpipe flange
This flange is used to fit the downpipe to the turbocharger, at the turbine outlet. All flanges are perfectly even and fit 100%. They are cut by water-jet or CNC milled to prevent warping.
Material: stainless steel
Material thickness: 10mm
Total dimensions: 106mm (outside diagonally), 76mm (outside without connections)
Dimensions cut-out: 70mm
Hole distance: 89mm (diagonal)
Thread: for M8
Extras / Features: no threads! 10mm holes!
For / Fits:
Turbo outlet 4-bolt / 63,5mm
Garrett GT2554R (GT25R) with T31 turbine housing (T3)
Garrett GT2560R (GT28R) with T31 turbine housing (T3)
Garrett GT2860RS (GT28R) with T3 4-bolt turbine housing as well as KKK K24/26
Garrett GT2871R with T3 4-bolt turbine housing as well as K24/26 (Audi S2 und RS2) turbine housing
Garrett GT2876R (GT25/40R) with T3 4-bolt as well as K24/26 turbine housing
Garrett GT3071R with T3 4-bolt turbine housing as well as K24/26 (Audi S2 und RS2) turbine housing
Garrett GT3076R (GT30R oder GT30RS) with T3 4-bolt as well as K24/26 turbine housing
Garrett GT3082R (GT30/40R) with T3 4-bolt turbine housing as well as KKK K24/26
Garrett GT3582R (GT35/40R oder GT35R) with T3 4-bolt as well as K24/26 turbine housing
Garrett T3 with 4-bolt turbine housing (mostly without internal wastegate)
Garrett T3 Super 60 with 4-bolt turbine housing (mostly without internal wastegate)
Garrett T3/T4 with 4-bolt turbine housing (mostly without internal wastegate)
KKK BorgWarner K24 Modelle
KKK BorgWarner K26 Modelle
KKK BorgWarner einige K27 Modelle
KKK K24/7200 (Audi RS2-turbocharger)
KKK K24/7000 (Audi S2-turbocharger)
If you are unsure whether this flange fits to your turbocharger, just draw a sketch of your turbine entry flange and hand it to us for comparison.
- Model: single flange
- Usage: Turbocharger to Downpipe
- Flange type: 4-Bolt 63.5mm
- Material: Stainless Steel
