Fuel / coolant temperature sensor 150°C / M14x1.5mm
Bosch Performance sensor for measuring water or fuel temperature
Compatible with our Displays / Gauges
Often with engine sensors, exhaust temperature measurement is the primary focus, but it’s equally important to monitor boost pressure, intake air, intercooler, or ambient temperature.
This sensor is designed to measure the temperature of liquids such as oil, water, or fuel. The signal can be used either as a control value for engine control units or as a measurement value logged in a data acquisition system.
The NTC element (Negative Temperature Coefficient) has a negative temperature coefficient, meaning conductivity increases as temperature rises. The measuring element of the temperature sensor consists of semiconductor heavy metal oxide and oxidized mixed crystals, protected within a housing.
The main advantage of this sensor lies in its combination of high-quality construction and a robust, compact design.
Technical Data:
- Type: NTC Sensor with steel housing (galvanized)
- Thread: M14x1.5mm male
- Installation Torque: 15 Nm
- Type: NTC
- Jetronic Connector 2-pin: 1 928 402 078
- Temperature-Resistant Cap, includes: 1 x 1 280 703 031
- Contact Pins for 0.5..1.0 mm² Tyco Number: 929 939-3
- Contact Pins for 1.5..2.5 mm² Tyco Number: 929 937-3
- Individual Seal for 0.5..1.0 mm² includes: 50 x 1 987 280 106
- Individual Seal for 1.5..2.5 mm² includes: 20 x 1 987 280 107
Combined with suitable evaluation circuits, these thermistors allow for precise temperature determination. Depending on the housing type, these sensors are suitable for measuring temperatures in liquids and gases. In vehicles, they measure the temperature of engine oil, coolant, fuel, intake air, and gas, in a range from -40 to 150°C.
Note:
For a 2-pin connector, 1 connector housing, 2 contact pins, and 2 individual seals are required.
Original AMP/Tyco crimp tools should be used for applications in the automotive sector.
- Availability: to order
