BorgWarner AirWerks S400SX3 SuperCore - 179172
For turbocharger S400SX3 (177248)
Original BorgWarner AirWerks Super Core
Note: Currently some compressor housings come without logo! This is not a quality difference! All components come directly from BW USA from the factory.
Super Cores are turbochargers without turbine housing. Or CHRA's incl. compressor housing. They are used as spare parts in case of damage or in case you want a combination with an turbine housing, which cannot be ordered directly. To mount the turbine housing you still need the mounting set, which should be renewed in any case in case of a repair. If the turbine housing has a wastegate flap, a pressure box and the matching retaining plate are required.
Fits turbocharger:
BorgWarner S400SX3 (177248)
Turbine wheel inducer: 83mm (exakter Wert ist 83,47mm)
Turbine wheel Exducer: 74,29mm
Compressor wheel inlet: 71,08mm
Compressor wheel outlet: 100,07mm
- Model: Without turbine housing
- Flange type: Without turbine housing
- Turbocharger: S400SX3
- a/r Value: Without turbine housing
